Under the high-quality terminal cap of each distributor is MSD's race-proven magnetic pick-up.
Both distributors are supplied with a high-quality cap, rotor, and gear. There is even a vacuum advance canister for street cruising economy!
- CARB E.O. Approved
- Designed for street/performance use with a mechanical and vacuum advance
- Must be used with an MSD Ignition Control
- CNC machined billet aluminum housing and billet aluminum base
- Vacuum advance canister for improved economy (can be locked out)
- Nylon pads ensure smooth operation of the advance weights
- Supplied with a socket style distributor cap and rotor
- Mechanical advance assembly can be locked out for crank trigger systems
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Advance weight pins are staked and tig welded to the plate
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing
Application Summary:
| Year |
Make/Model |
| 1974-1983 |
Jeep Cherokee |
| 1972-1978 |
Jeep CJ5 |
| 1972-1975 |
Jeep CJ6 |
| 1976-1978 |
Jeep CJ7 |
| 1986 |
Jeep CJ7 |
| 1972-1973 |
Jeep Commando |
| 1972-1974 |
Jeep DJ5 |
| 1965-1967 |
Jeep Gladiator |
| 1984-1986 |
Jeep Grand Wagoneer |
| 1965-1971 |
Jeep J-100 |
| 1968-1973 |
Jeep J-2500 |
| 1968-1970 |
Jeep J-2600 |
| 1972-1973 |
Jeep J-2600 |
| 1968-1969 |
Jeep J-2700 |
| 1968-1970 |
Jeep J-3500 |
| 1968-1970 |
Jeep J-3600 |
| 1968-1970 |
Jeep J-3700 |
| 1968 |
Jeep J-3800 |
| 1974-1976 |
Jeep J10 |
| 1978-1987 |
Jeep J10 |
| 1974 |
Jeep J20 |
| 1976 |
Jeep J20 |
| 1981-1985 |
Jeep Scrambler |
| 1972-1973 |
Jeep Wagoneer |
| 1987-1988 |
Jeep Wrangler |
| Attributes |
| ASIN |
B000COOMFS |
| Brand |
MSD, MSD |
| C.A.R.B. EO # |
D-40-39 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category |
Ignition, Ignition |
| Color |
Red, Red |
| Country of Origin (Primary) |
US |
| Distributor Cap Included |
Yes |
| Distributor Type |
Magnetic Pickup, Magnetic Pickup |
| Emission Code |
1, 1, Legal US |
| Engine |
AMC/Jeep 4.0L Inline 6, AMC/Jeep 4.0L Inline 6 |
| Engine Make/Size |
AMC 199-258 |
| GTIN |
00085132085163 |
| Gear Material |
Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8511300040 |
| Hazardous Material Code |
N |
| Ignition Box Required |
Yes |
| Ignition Coil Included |
No |
| Ignition Rotor Included |
Yes |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Product Type |
Distributor, Distributor |
| SDR Required Flag |
N |
| Series |
Pro Billet Distributors |
| Sub Category |
Distributor and Magneto, Distributor and Magneto |
| Subcategory |
Distributors |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time |
12 |
| part type |
Distributor, Distributor |
