VW Type I (air cooled) Billet distributor requires an MSD 6 or 7-series ignition.
A maintenance-free magnetic pickup is responsible for triggering the MSD Ignition. This pickup is accurate to within 1° at any rpm so you won't have to worry about points float or "burbles" at top end speeds. The pickup is triggered by a precision reluctor that is attached to a hardened steel shaft. For increased stability, a sealed ball bearing is used to guide the shaft. Since every engine application is different, the MSD Billet distributor features an easy-to-adjust mechanical advance assembly. By simply changing the advance springs and stop bushing you can tune in 24 different advance curves.
A maintenance-free magnetic pickup is responsible for triggering the MSD Ignition. This pickup is accurate to within 1° at any rpm so you won't have to worry about points float or "burbles" at top end speeds. The pickup is triggered by a precision reluctor that is attached to a hardened steel shaft. For increased stability, a sealed ball bearing is used to guide the shaft. Since every engine application is different, the MSD Billet distributor features an easy-to-adjust mechanical advance assembly. By simply changing the advance springs and stop bushing you can tune in 24 different advance curves.
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Mechanical advance assembly can be locked out for crank trigger systems
- Supplied with bolt down distributor cap and rotor
- Designed as a performance upgrade for VW Type I air cooled engines
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing
- CNC machined billet aluminum housing and Dupont Rynite base
- Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- No CARB Exemption Order Number
- Advance weight pins are staked and tig welded to the plate• Nylon pads ensure smooth operation of the advance weights
- Must be used with an MSD Ignition Control
| Attributes | |
| ASIN | B000COSSO4 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Gray, Gray |
| Country of Origin (Primary) | US |
| Distributor Cap Included | Yes |
| Distributor Type | Single Point, Magnetic Pickup |
| Emission Code | 3, 3, Off Road |
| Engine Make/Size | VW Type 1 |
| GTIN | 00085132084852 |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511300040 |
| Hazardous Material Code | N |
| Ignition Box Required | Yes |
| Ignition Coil Included | No |
| Ignition Rotor Included | Yes |
| Life Cycle Status Code | Available to Order |
| Make | Volkswagen, Volkswagen |
| NAFTA Preference Criterion Code | B |
| Product Type | Distributor, Distributor |
| SDR Required Flag | N |
| Sale Category | Ignition |
| Series | Pro Billet Distributors |
| Sub Category | Distributor and Magneto, Distributor and Magneto |
| Subcategory | Distributors |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| part type | Distributor, Distributor |
MSD Performance 8485 VW Billet Distributor
Product Information
- Brand: MSD Performance
- Product Number: 8485
