Small diameter distributor for 351C-460, includes iron gear and vacuum advance. Must be used with an MSD 6, 7 or 8-series ignition.

Mounted to the top of this shaft is a fully adjustable mechanical advance assembly. The rate at which the chromoly assembly advances the timing is easily controlled by changing the supplied advance springs and stop bushing for total advance.

Mechanical advance assembly can be locked out for crank trigger systems
Billet housing is 5/8” smaller in diameter than stock Ford distributors
Must be used with an MSD Ignition Control
CNC machined billet aluminum housing and billet aluminum base
Supplied with small diameter cap with HEI style terminals and race rotor (will accept 8441 Cap-A-Dapt)
Advance weight pins are staked and tig welded to the plate
Polished steel shaft is QPQ coated and guided by a sealed ball bearing
CARB E.O. Approved
Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
Easy-to-adjust mechanical advance with supplied springs and stop bushings
Vacuum advance canister for improved economy (can be locked out)
Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction
Nylon pads ensure smooth operation of the advance weights

Application Summary:

Year	Make/Model
1978-1979	Ford Bronco
1971-1974	Ford Country Sedan
1971-1974	Ford Country Squire
1971-1972	Ford Custom
1971-1977	Ford Custom 500
1978	Ford E-100 Econoline
1979-1980	Ford E-150 Econoline
1975-1980	Ford E-250 Econoline
1975-1989	Ford E-250 Econoline Club Wagon
1991	Ford E-250 Econoline Club Wagon
1975-1989	Ford E-350 Econoline
1991-1996	Ford E-350 Econoline
1977-1989	Ford E-350 Econoline Club Wagon
1991-1996	Ford E-350 Econoline Club Wagon
1975-1976	Ford Elite
1973-1974	Ford F-100
1977-1979	Ford F-100
1975-1979	Ford F-150
1970	Ford F-250
1973-1989	Ford F-250
1991-1997	Ford F-250
1997	Ford F-250 HD
1973-1989	Ford F-350
1991-1997	Ford F-350
1971-1974	Ford Galaxie 500
1972-1976	Ford Gran Torino
1971-1978	Ford LTD
1977-1978	Ford LTD II
1971-1974	Ford Ranch Wagon
1972-1978	Ford Ranchero
1972-1978	Ford Thunderbird
1972-1976	Ford Torino
1968-1979	Lincoln Continental
1968-1971	Lincoln Mark III
1972-1976	Lincoln Mark IV
1977-1979	Lincoln Mark V
1971-1974	Mercury Colony Park
1973-1978	Mercury Cougar
1975-1978	Mercury Grand Marquis
1971-1978	Mercury Marquis
1972-1976	Mercury Montego
1971-1974	Mercury Monterey

Attributes
ASIN	B000COUQA8
Brand	MSD, MSD
C.A.R.B. EO #	D-40-39
California Proposition 65	WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Category	Ignition, Ignition
Color	Red, Red
Country of Origin (Primary)	US
Distributor Cap Included	Yes
Distributor Type	HEI/Breakerless, Magnetic Pickup
Emission Code	1, 1, Legal US
Engine	Ford 351C-460, Ford 351C-460
Engine Make/Size	Ford 351C
GTIN	00085132084777
Gear	Cast Iron, Cast Iron
Gear Material	Cast Iron Melonized QPQ Coated, Cast Iron Melonized QPQ Coated
Grade Type	Performance
Harmonized Tariff Code (Schedule B)	8511300040
Hazardous Material Code	N
Ignition Box Required	Yes
Ignition Coil Included	No
Ignition Rotor Included	Yes
Life Cycle Status Code	Available to Order
NAFTA Preference Criterion Code	B
Product Type	Distributor, Distributor
SDR Required Flag	N
Series	Pro Billet Distributors
Sub Category	Distributor and Magneto, Distributor and Magneto
Subcategory	Distributors
Warning	California Proposition 65, California Proposition 65
Warranty	Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty
Warranty Time	12
part type	Distributor, Distributor
