Fits 368, 425, 472 and 500 Cadillac V8. Must be used with an MSD 6, 7 or 8-series ignition. Includes vacuum advance.
MSD's race proven magnetic pickup supplies a trigger signal that is accurate to within one degree at any rpm. Mounted above this pickup is an adjustable mechanical advance and is supplied with different springs and stop bushings for a number of curves. For street cruising economy, as if there's any such thing in a Caddy, there is a vacuum advance canister.
- Special oil tract improves lubrication to the distributor and cam gear
- Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range
- Must be used with an MSD Ignition Control
- Designed for Cadillac 368, 425, 472 and 500 ci engines
- Easy-to-adjust mechanical advance with supplied springs and stop bushings
- Supplied with an HEI style distributor cap and rotor (accepts Cap-A-Dapts)
- CNC machined billet aluminum housing and billet aluminum base
- Mechanical advance assembly can be locked out for crank trigger systems
- Vacuum advance canister for improved economy (can be locked out)
- CARB E.O. Approved
- Polished steel shaft is QPQ coated and guided by a sealed ball bearing
Application Summary:
| Year |
Make/Model |
| 1965-1976 |
Cadillac Calais |
| 1964-1981 |
Cadillac DeVille |
| 1964-1978 |
Cadillac Eldorado |
| 1980-1981 |
Cadillac Eldorado |
| 1965-1984 |
Cadillac Fleetwood |
| 1964 |
Cadillac Series 60 Fleetwood |
| 1964 |
Cadillac Series 62 |
| 1964 |
Cadillac Series 75 Fleetwood |
| 1980-1981 |
Cadillac Seville |
| Attributes |
| ASIN |
B000ECHBJW |
| Brand |
MSD, MSD |
| C.A.R.B. EO # |
D-40-39 |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category |
Ignition, Ignition |
| Color |
Red, Red |
| Country of Origin (Primary) |
US |
| Distributor Cap Included |
Yes |
| Distributor Type |
HEI/Breakerless, Magnetic Pickup |
| Emission Code |
1, 1, Legal US |
| Engine Make/Size |
Cadillac 368-500 |
| GTIN |
00085132083633 |
| Gear Material |
Steel Melonized QPQ Coated, Steel Melonized QPQ Coated |
| Grade Type |
Performance |
| Harmonized Tariff Code (Schedule B) |
8511300040 |
| Hazardous Material Code |
N |
| Ignition Box Required |
Yes |
| Ignition Coil Included |
No |
| Ignition Rotor Included |
Yes |
| Life Cycle Status Code |
Available to Order |
| NAFTA Preference Criterion Code |
B |
| Product Type |
Distributor, Distributor |
| SDR Required Flag |
N |
| Series |
Pro Billet Distributors |
| Sub Category |
Distributor and Magneto, Distributor and Magneto |
| Subcategory |
Distributors |
| Warning |
California Proposition 65, California Proposition 65 |
| Warranty |
Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time |
12 |
| part type |
Distributor, Distributor |
