Universal - Use with MSD Ignition Box - 90 Degree Terminal and Boot Included
If you are looking to upgrade your stock coil, or want to compliment the performance of your MSD Blaster Ignition, MSD 5, 6, or 7, the Blaster Coil line is the right choice. Our Blaster Coils are designed for improved spark output! Special 100:1 windings are used to provide maximum build-up of voltage! These windings are held secure and kept cool in an oil-filled metal canister.
If you are looking to upgrade your stock coil, or want to compliment the performance of your MSD Blaster Ignition, MSD 5, 6, or 7, the Blaster Coil line is the right choice. Our Blaster Coils are designed for improved spark output! Special 100:1 windings are used to provide maximum build-up of voltage! These windings are held secure and kept cool in an oil-filled metal canister.
- Supplied with a 90° spark plug style terminal and boot
- CARB E.O. Approved
- MSD Red metal canister is filled with a premium grade oil for cooling
- Extra tall secondary tower for secure coil wire connection
- Improved output coil for electronic ignitions, and MSD Ignitions (ballast resistor required for points)• 100:1 turns ratio and lower primary resistance produce high voltage output
Information:
CARB EO: D-40-37| Attributes | |
| ASIN | B00029JLB8 |
| Brand | MSD, MSD |
| C.A.R.B. EO # | D-40-37 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Country of Origin (Primary) | CN |
| Emission Code | 1, 1, Legal US |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | 8 mH |
| Inductance (mH) | 8 |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 45000, 45,000 Volts |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Coil |
| Peak Current | 140 mA, 140 |
| Primary Resistance | .700 ohms, .7 OHMs |
| Product Type | Coil, Coil |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Resistance | 4.5K ohms, 4.5K |
| Series | Blaster Performance Coils |
| Spark Duration | 350 uS, 0.35 |
| Sub Category | Ignition Coil |
| Subcategory | Coils and Parts |
| Turns Ratio | 100:1, 4.167361111111111 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight | N/A |
| GTIN | 00085132082230 |
