Universal - Add To Any MSD 6-Series Ignition
Don't let the compact size of the Blaster SS Coil fool you, because it is packed with performance! The efficient E-core windings are designed to produce high amounts of current without sacrificing the voltage output. In fact, when used with an MSD 6 Series Ignition, the Blaster SS produces 300 milliamps of current and maximum voltage output of 40,000 volts!
Don't let the compact size of the Blaster SS Coil fool you, because it is packed with performance! The efficient E-core windings are designed to produce high amounts of current without sacrificing the voltage output. In fact, when used with an MSD 6 Series Ignition, the Blaster SS produces 300 milliamps of current and maximum voltage output of 40,000 volts!
- Tough, rigid housing with a tall tower and brass primary terminals
- 70:1 turns ratio and lower primary resistance produce high voltage output
- Efficient winding design and assembly creates a compact housing
- Improved output coil for electronic ignitions, and MSD Ignitions
- Primary and secondary windings are encased in Ciba polyurethane
| Attributes | |
| ASIN | B00029JKG4 |
| Brand | MSD, MSD |
| C.A.R.B. EO # | D-40-37 |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Coil Type | Blaster, Blaster |
| Color | Red, Red |
| Country of Origin (Primary) | CN |
| Emission Code | 1, 1, Legal US |
| Harmonized Tariff Code (Schedule B) | 8511300080 |
| Hazardous Material Code | N |
| Inductance | 6.9 mH |
| Inductance (mH) | 6.9 |
| Item Weight | 1.080 lbs. |
| Life Cycle Status Code | Available to Order |
| Maximum Voltage | 40,000 Volts, 40,000 |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Coil |
| Peak Current | 300 mA, 300 |
| Primary Resistance | .355 ohms, 0.355 |
| Product Type | Coil, Ignition Coil |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Resistance | 4.4K ohms, 4.4K |
| Series | Blaster Performance Coils |
| Spark Duration | 220 uS, 0.22 |
| Sub Category | Ignition Coil |
| Subcategory | Coils and Parts |
| Turns Ratio | 70:1, 2.917361111111111 |
| Type | Blaster |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight | 1.08 lbs., 1.08 |
| GTIN | 00085132082070 |
