If your running alcohol and high compression and/or a turbo/blower this one can ignite it all.
There has always been a niche group of hardcore racers and pullers that run nothing but the MSD 8 Ignition Series. If you liked it then, you're going to like it even better now!
There has always been a niche group of hardcore racers and pullers that run nothing but the MSD 8 Ignition Series. If you liked it then, you're going to like it even better now!
- Compatible for 4, 6 and 8-cylinders
- Built-in 2-step rev control
- 12-18 Volts, Negative Ground
- Extreme spark output
- 36 Amps at 12,000 RPM
- Single or dual coil output
- 15,000 RPM with 14.4 Volts
| Attributes | |
| ASIN | B004A6DFS4 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Gold |
| Connector Gender | Terminal Strip |
| Connector Quantity | 1 |
| Country of Origin (Primary) | US |
| Current Draw | 36 Amp at 12000 RPM, 36 Amps at 12,000 RPM |
| Emission Code | 4, 4, Off Road |
| Features | Extreme Cylinder Pressure, Extreme Cylinder Pressure |
| Grade Type | Race |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Height | 5.75 |
| Ignition Type | Performance |
| Length | 8.25 |
| Life Cycle Status Code | Available to Order |
| Maximum RPM | 15,000 |
| Mount Type | Surface Mount, Surface Mount |
| Mounting Hardware Included | Yes, Yes |
| NAFTA Preference Criterion Code | B |
| part type | Ignition Control Module |
| Primary Voltage | 480, 480 Volts |
| Product Type | Ignition Box, Ignition Box |
| RPM | 15000 |
| RPM Range | 15,000 RPM with 14.4 Volts |
| Sale Category | Ignition |
| SDR Required Flag | N |
| Secondary Voltage | 50000, 50,000 Volts Plus |
| Series | Drag Racing Ignitions |
| Spark Duration | 20 Degree Crankshaft Rotation |
| Spark Energy | 315-345 mJ per spark, 315-345 mJ per spark |
| Spark Energy (mJ per spark) | 315-345 |
| Spark Series Duration | 20 Degree Crankshaft Rotation, 20 Degree Crankshaft Rotation |
| Sub Category | Control Modules, Control Modules |
| Subcategory | Racing Electronics |
| Terminal Gender | Terminal Strip |
| Terminal Quantity | 14 |
| Voltage | 12-18 V; Negative Ground |
| Voltage Required | 12-18 Volts, Negative Ground, 12-18 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight and Size | 4.85 lbs.,8.25"L x 3.75"W x 5.75"H, 4.85 lbs., 8.25L x 3.75W x 5.75H |
| Width | 3.75 |
| GTIN | 00085132078059 |
