Universal - Soft Touch 2 Step Rev Control - 1 Stage Retard Control - Start Retard
For nitrous-equipped cars, the Digital-6 Plus offers a step retard that will retard the timing when the nitrous is activated. There is also a 2-step rev limiter for holeshot consistency and overrev protection.
For nitrous-equipped cars, the Digital-6 Plus offers a step retard that will retard the timing when the nitrous is activated. There is also a 2-step rev limiter for holeshot consistency and overrev protection.
- 12,500 RPM with 14.4 Volts
- Adjustable magnetic pickup compensation produces accurate trigger signals.
- Switch between two rev limits that adjust with rotary switches in 100 rpm increments.
- 12-18 Volts, Negative Ground
- LED display warns of trigger signal problems or faulty charging system.
- Start retard eases pressure on the starter, flywheel and engine.
- .7 Amp per 1,000 RPM
- Single stage retard for nitrous and top end performance.
Information:
CARB EO # D-722-2| Attributes | |
| ASIN | B00029JKC8 |
| Brand | MSD, MSD |
| California Proposition 65 | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Category | Ignition, Ignition |
| Color | Red, Red |
| Connector Gender | Male Female |
| Connector Quantity | 1 |
| Country of Origin (Primary) | US |
| Current Draw | .7 Amp per 1000 RPM, .7 Amp per 1,000 RPM |
| Emission Code | 1, 1, Legal US |
| GTIN | 00085132065202 |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8511804000 |
| Hazardous Material Code | N |
| Height | 2.2 |
| Ignition Type | Performance |
| Length | 8.5 |
| Life Cycle Status Code | Available to Order |
| Maximum RPM | 12,500 |
| Mount Type | Surface Mount, Surface Mount |
| Mounting Hardware Included | Yes, Yes |
| NAFTA Preference Criterion Code | B |
| Primary Voltage | 535, 535 Volts |
| Product Type | Digital 6-Plus Ignition Control Box, Digital 6-Plus Ignition Control Box |
| RPM | 12500 |
| RPM Range | 12,500 RPM with 14.4 Volts |
| SDR Required Flag | N |
| Sale Category | Ignition |
| Secondary Voltage | 45000, 45,000 Volts |
| Series | 6-Series Ignitions |
| Spark Duration | 20 Degree Crankshaft Rotation |
| Spark Energy | 135 mJ per spark |
| Spark Energy (mJ per spark) | 135 |
| Spark Series Duration | 20° Crankshaft Rotation, 20° Crankshaft Rotation |
| Sub Category | Control Modules, Control Modules |
| Subcategory | Ignition Boxes |
| Terminal Gender | Male Female |
| Terminal Quantity | 10 |
| Voltage | 12-18 V; Negative Ground |
| Voltage Required | 12-18 Volts, Negative Ground, 12-18 |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 1 Year Warranty, Manufacturer's Limited 1 Year Warranty |
| Warranty Time | 12 |
| Weight and Size | 3.7 lbs., 8.5"L x 4.5"W x 2.2"H, 3.7 lbs., 8.5L x 4.5W x 2.2H |
| Width | 4.5 |
| part type | Ignition Control Module |
MSD Performance 6520 MSD Digital 6-Plus Ignition Control
Product Information
- Brand: MSD Performance
- Product Number: 6520
