One of the biggest weapons in oil-control technology is the trap-door baffle within an oil pan. Unlike static baffles, trap-door baffles open and close to allow almost unrestricted one-way fluid flow, while effectively limiting flow in the opposite direction. The baffle assemblies are arranged in a way that allows oil to move from non-pickup areas to the sump pickup area, through the use of baffle doors that have wire hinges that open approximately 1/3 of the way (so the door can close quickly without allowing too much oil to pass through). The simplest of all the Moroso baffle designs is the Street/Strip and Drag Racing oil pan that only needs to control oil in two directions, forward and backward (under acceleration and deceleration). All of these oil pans incorporate a horizontal baffle that allows oil to move toward the pickup while accelerating, and prevents oil from leaving the pickup area while decelerating.

• Wet Sump
• Steel
• Trap Door Baffle
• 6qt
• 8.25 deep
• For SBC1980-'85 Blocks with Passenger-Side Dipstick
• Fits Most chassis (NOT '62-67 Chevy II/V8 Vega/Monza)
• Clears 4.125” stroke with most steel rods
• Fits 4 bolt Dart/GM/Merlin main caps

---

Information:

Wet Sump; Steel; Clear Zinc; Street Performance; 6 Quart Capacity; 8-1/4 deep; For Small Block Chevy 1980-'85 Blocks with Passenger-Side Dipstick; Fits Most chassis (except 1962-67 Chevy II, V8 Vega and Monza); Clears 4.125” stroke with most steel rods; Fits 4 bolt Dart, GM, and Merlin main caps; Trap door baffle for improved oil control; RECOMMENDED PICKUPS: PN: 24170 (Fits Moroso SBC Race Pump PN: 22099, 22101 or M55 style pump), PN: 24181 (Fits SBC 3/4 Inlet, M10552/M10555 Style Pumps), PN: 24350 (Fits Moroso SBC HV Race Pump PN: 22109, 22111 or M55HV style pump), PN: 24320 (Fits Moroso BBC Race Pump No. 22150 or M77HV style pump), PN: 24360 (Fits M155HV style pump); OIL PUMP/PICKUP PACKAGE: PN: 22124 Moroso Standard Volume Package, PN: 22134 Moroso High Volume Package, PN: 22146 Moroso High Volume Package w/ 3⁄4 dia. inlet, PN: 22139 Moroso High Volume with Anti-Cavitation Grooves Package, PN: 22171 Moroso Billet Aluminum Oil Pump; AVAILABLE OIL PAN OPTIONS: PN: 23020 Windage Tray, PN: 23000 Oil Pan Baffle, PN: 25800 Crank Scraper, PN: 38551 SBC Oil Pan Flange Head Bolts, PN: 93150 Pre-'85 block with a 2 piece rear main seal Oil Pan Gasket.
