One of the biggest weapons in oil-control technology is the trap-door baffle within an oil pan. Unlike static baffles, trap-door baffles open and close to allow almost unrestricted one-way fluid flow, while effectively limiting flow in the opposite direction. The baffle assemblies are arranged in a way that allows oil to move from non-pickup areas to the sump pickup area, through the use of baffle doors that have wire hinges that open approximately 1/3 of the way (so the door can close quickly without allowing too much oil to pass through).

• Wet Sump
• Steel
• Trap Door Anti-slosh baffle
• 7qt
• '98-02 Camaro/Firebird with GM LS Engines & '93-'02 Camaro/Firebird with LS Swap
• Clears 4.25 stroke with steel rods
• Mount 22mm thread/OEM oil filter in stock location
• Use stock dipstick

---

Information:

Wet Sump; Steel; 7 Quart Capacity; Designed for '98-'02 Camaro and Firebird with GM LS Engines and '93-'02 Camaro and Firebird with LS Swap; Drag race proven trap door assembly and anti-slosh baffle that keeps oil contained in oil pump pick up area; Oil pan has a thick precision laser cut steel rail with a clear zinc finish; Clears 4.25 stroke with most steel rods and can be used with Moroso No. 22941 windage tray; The 7 Quart Capacity moves the oil away from the rotating assembly for oil control and horsepower saving; Billet aluminum adapter that allows a 22mm thread Moroso No. 22463 or OEM oil filter to be mounted in the stock location, no need to run a remote oil filter; Includes billet aluminum oil filter adapter has a ¼ N.P.T. sensor port; Uses stock dipstick; PN: 24050 is recommended (Fits stock oil pumps or Moroso LS Series High Volume Race Pump PN: 22120); Available oil pan options are PN: 22120 GM LS Race Oil Pump, PN: 22463 Moroso Racing Oil Filter, PN: 24890 GM LS Oil Pump Flange Reinforcement, PN: 38541 Oil Pan Mounting Stud Kit, PN: 71162 Dust Shield for Moroso & Aftermarket Oil Pans, & PN: 93152 GM LS Oil Pan Gasket.

---

Application Summary:

Year	Make/Model
Chevrolet	GM F-Body
Camaro	& Firebird '98-02 with GM LS Engines
Camaro	& Firebird '93-'02 with LS Swap
