Dual Injector Manifold and Fuel Rails- Black Finish
the packaging of a plenum mounted air-to-water intercooler for forced induction (supercharged or
the packaging of a plenum mounted air-to-water intercooler for forced induction (supercharged or
- High volume fuel rails for eight and sixteen injector configurations. Mounting hardware included with3/4-16 O-ring ports (8 AN)and mounting hardware included with 3/4-16 O-ring ports (8 AN)
- Provides best performance for forced induction (supercharged or turbocharged) engine applications with peak power at 7000-8000 rpm, depending on the application
- Dual-injector, separate-passage, high-volume fuel rails with mounting hardware, dual-fuel capable, 8 AN o-ring ports
- Low height to aid the packaging of a plenum mounted air-to-water intercooler in a top-feed configuration
- Available with both as-cast satin and black power-coat finishes
- Designed for GM LS Gen III and IV engines equipped with GM LS3/L92 cylinder heads
| Attributes | |
| Basic Operating RPM Range | 3500-8000 |
| Brand | Holley EFI, Holley EFI |
| CNC Ported | No |
| California Proposition 65 | No |
| Carburetor Flange | N/A |
| Carburetor Quantity | N/A |
| Carburetor Studs Included | N/A |
| Category | Air and Fuel Delivery, Intake Manifolds |
| Category Filter | Intake Manifolds |
| Clearance Category | Intake Manifolds |
| Color | Black, Black |
| Construction | Cast, Cast |
| Country of Origin (Primary) | CN |
| Cylinder Head Port Shape | Rectangle |
| Cylinder Head Type | LS3/L92 |
| Deck Height | 9.24 |
| EGR Port | No, No |
| Emission | N/A |
| Emission Code | 3, 3, Off Road |
| Engine | GM LS3/L92, GM LS3/L92 |
| Engine Make/Size | Chevy LS3 |
| Finish | Black |
| Flange Style | N/A |
| Fuel Injectors Included | No, No |
| Fuel System Type | EFI, EFI |
| GTIN | 00090127100967 |
| Gasket Or Seal Included | Yes, Yes |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Injector Quantity | Dual, Dual |
| Inlet Location | Top, Top |
| Life Cycle Status Code | Available to Order |
| Manifold Type | Lo-Ram, Lo-Ram |
| Material | Aluminum, Aluminum |
| NAFTA Preference Criterion Code | B |
| Number of Carbs | None; For Fuel Injection |
| Plenum Finish | Black, Black |
| Position | Upper |
| Product Type | Intake Manifold Base, Intake Manifold Base |
| RPM Power Band | 3500-8000 RPM, 3500-8000 |
| RPM Range | 7000-8000 |
| Recommended Use | Forced Induction, Forced Induction |
| SDR Required Flag | N |
| Sale Category | Air and Fuel Delivery |
| Single Or Dual Plane Type | Single Plane, Single Plane |
| Sub Category | Cylinder Block Components, Cylinder Block Components |
| Throttle Body Bore Diameter | 105 MM, 105 MM |
| Throttle Body Gasket Included | Yes |
| Usage | Street/Strip |
| Vacuum Ports | Yes |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| part type | Engine Intake Manifold, Engine Intake Manifold |
Holley EFI 300-683BK Holley Lo-Ram Manifold Kit Dual Injector- Black - GM LS3/L92
Product Information
- Brand: Holley EFI
- Product Number: 300-683BK
