Marine Carbureted Applications Compatible with Gasoline Only

---

The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all times. They have been powering racing legends and street enthusiasts alike since the early 70's. Their time proven rotor/vane design is known to get the job done in an affordable package. Designed with a fume tube for marine use and meets U.S. Coast Guard regulations.

• Tumble polished billet look
• Can be serviced from the pump end
• Not compatible with alcohol or methanol fuels
• Lower housing casting designed for enhanced fuel flow and quiet operation
• Use of safety shut-off switch, P/N 12-810, strongly recommended
• Not designed or recommended for use with fuel injection systems
• Meets U.S. Coast Guard regulations
• Includes Fuel/vapor tube
• Motor draws only 3 amps current
• 7 1/2 amp fuse recommended
• Improved design for street/strip applications
• maximum pressure is 14 psi
• Not designed to be used on aircraft of any type.
• Distinctive “Blue” logo
• Flows 110 GPH (free flow)
• Flows 88 GPH at 9 psi
• Includes P/N 12-803 fuel pressure regulator
• Provides constant fuel flow with no pulsation
• Has externally accessible pressure relief valve (max 14 psi)
• Rotor/vane pump design is more tolerant of contaminated fuels
• Weighs only 3 lbs
• Includes mounting bracket
• Repair kits are readily available

---

Information:

Should be mounted below the fuel level of the tank for a good gravity feed on the inlet side. These are to be used with 12 volt systems only.

---
