Fits VVT Gen III Hemi Engines - 2009-up 5.7L & 2011-up 6.4L Engines . Mid-Sump Design Fits 1963-1974 Mopar A-Body, B-Body, C-Body & E-Body

---

The cast aluminum construction & integrated windage tray on the oil pans combined with o-ring sealing provide an attractive leak-free solution for your engine swap. Complete oil pan kit that includes all the parts needed for installation (i.e. oil pan, pickup assembly, o-ring seal, windage tray, baffling & mounting bolts).

• The Factory Oil Pans on Gen III Hemi Engines Don’t Fit or Hang too Low for Muscle Car Engine Swaps
• Works with Most Factory & Aftermarket Dipsticks
• Patent Pending
• Complete Oil Pan Kit That Includes Oil Pan, Pickup Assembly, O-Ring Seal, Windage Tray, Baffling & Mounting Bolts – No Extras That Must be Purchased Separately (i.e. gaskets, pickup, windage tray, bolts)
• Cast Aluminum Mid-Sump Engine Swap Oil Pan
• Unique O-Ring Seal to Block and Captured Windage Tray (Patent Pending)
• Integrated Windage Tray & Baffle to Control Oil (Fits up to 4.060” Stroke)
• Part # 302-61 Fits Early Engines with Variable Valve Timing (VVT) 2009-up 5.7L, 2011-up 6.4L Engines
• Fits 1963-1974 Mopar A-Body, B-Body, C-Body, and E-Body – See the Vehicle Application Tab
• Oil Capacity – 6 Quarts (6.5 Quarts w/ Filter)

---

Information:

Most engines came from the factory with a stud in the block that is reused to mount the oil pickup. If you don't have this stud it can be purchased from Mopar - part number 06513100AA. Recommended Dipstick: Any dipstick from a Dodge or Ram truck that was originally equipped with a Gen III Hem engine is compatible with this oil pan. These dipsticks mate to the engine block dipstick port. Note: Fitment not guaranteed when using aftermarket exhaust. The oil return ports on the front corners of the oil pan are no longer machined (the bosses are still there & can be drilled and tapped for these ports - if needed).

---

Application Summary:

Year	Make/Model
1963-1974	Chrysler Imperial
1963-1974	Chrysler New Yorker
1963-1974	Chrysler Newport
1963-1974	Chrysler Town & Country
1963-1964	Dodge 330
1963-1964	Dodge 440
1970-1974	Dodge Challenger
1966-1974	Dodge Charger
1963-1974	Dodge Coronet
1963-1976	Dodge Dart
1965-1974	Dodge Monaco
1963-1973	Dodge Polara
1964-1974	Plymouth Barracuda
1963-1971	Plymouth Belvedere
1970-1974	Plymouth Cuda
1970-1976	Plymouth Duster
1963-1974	Plymouth Fury
1965-1974	Plymouth Fury III
1972-1974	Plymouth Gran Fury
1967-1971	Plymouth GTX
1968-1975	Plymouth Road Runner
1965-1974	Plymouth Satellite
1963-1964	Plymouth Savoy
1971-1976	Plymouth Scamp
1970	Plymouth Superbird
1963-1976	Plymouth Valiant
