Fits GM/Muscle Car/Classic Car/Trucks and other LS Swap Projects
-Christopher Campbell, Popular Hot Rodding Magazine
-Christopher Campbell, Popular Hot Rodding Magazine
- Provides OE Style fitment - OE oil filter mounting, OE oil cooler port provision, OE engine NVH suppression, OE flange gasket and sealing, proper structural rigidity and OE bell-housing attachments
- Traditional high-quality cast aluminum appearance with clean exterior styling.
- Provides maximum clearance to chassis
- Cast and machined aluminum
- Complete kit including sump baffle, pick-up tube, sump plug, oil filter stud & oil passage cover.
- Fits GM rear wheel drive applications that were originally equipped with a Small Block or Big Block Chevy engine and traditional rear sump oil pan*
- Maximum crankshaft stroke = 4.25"
Information:
Maximum crankshaft stroke = 4.25" Sump Oil Capacity - 5.5 Quarts Total Oil Capacity with stock oil filter - 6 Quarts Oil Filter (AC Delco®, PF48 or PF48E, Mobile M1-113, Wix 57060, K&N HP-1017, or equivalent) Requires use of Holley 302-15 Dipstick and Tube Kit or LS3 dipstick (GM P/N 12669528) and tube (GM P/N 12625031) *Engine location may need to be adjusted (up / down or fore / aft) for cross member or steering linkage clearance depending on the vehicle, steering configuration and chassis type. For G-Body applications, use part number 302-2 as the 302-1 swap oil pan is not compatible with a G-Body.Application Summary:
| Year | Make/Model |
|---|---|
| 1955-1963 | Chevrolet Bel Air |
| 1966 | Chevrolet Bel Air |
| 1958-1963 | Chevrolet Biscayne |
| 1966 | Chevrolet Biscayne |
| 1973-1974 | Chevrolet Blazer |
| 1987-1991 | Chevrolet Blazer |
| 1975-1986 | Chevrolet C10 |
| 1960-1963 | Chevrolet C10 Pickup |
| 1973-1974 | Chevrolet C10 Pickup |
| 1973-1986 | Chevrolet C10 Suburban |
| 1982-1988 | Chevrolet C15 |
| 1975-1987 | Chevrolet C20 |
| 1960-1963 | Chevrolet C20 Pickup |
| 1973-1974 | Chevrolet C20 Pickup |
| 1973-1986 | Chevrolet C20 Suburban |
| 1960-1963 | Chevrolet C30 Pickup |
| 1970-1981 | Chevrolet Camaro |
| 1957-1963 | Chevrolet Corvette |
| 1966-1969 | Chevrolet Corvette |
| 1957-1958 | Chevrolet Del Ray |
| 1959-1960 | Chevrolet El Camino |
| 1958-1963 | Chevrolet Impala |
| 1966 | Chevrolet Impala |
| 1960-1963 | Chevrolet K10 Pickup |
| 1960-1963 | Chevrolet K20 Pickup |
| 1975-1986 | Chevrolet K5 Blazer |
| 1958-1961 | Chevrolet Nomad |
| 1955-1957 | Chevrolet One-Fifty Series |
| 1960-1963 | Chevrolet P20 Series |
| 1960-1963 | Chevrolet P30 Series |
| 1987 | Chevrolet R10 |
| 1987-1988 | Chevrolet R10 Suburban |
| 1987-1988 | Chevrolet R20 |
| 1987-1988 | Chevrolet R20 Suburban |
| 1982-2004 | Chevrolet S10 |
| 1957-1963 | Chevrolet Suburban |
| 1957-1960 | Chevrolet Truck |
| 1957 | Chevrolet Two-Ten Series |
| 1975-1978 | GMC C15 |
| 1975-1978 | GMC C15 Suburban |
| 1973-1974 | GMC C15/C1500 Suburban |
| 1979-1986 | GMC C1500 Suburban |
| 1975-1978 | GMC C25 |
| 1975-1978 | GMC C25 Suburban |
| 1973-1974 | GMC C25/C2500 Pickup |
| 1973-1974 | GMC C25/C2500 Suburban |
| 1979-1986 | GMC C2500 |
| 1973-1991 | GMC Jimmy |
| 1987 | GMC R1500 |
| 1987 | GMC R1500 Suburban |
| 1987 | GMC R2500 |
| 1987 | GMC R2500 Suburban |
| 1982-1990 | GMC S15 |
| 1991-2004 | GMC Sonoma |
| 1987 | Jeep Wrangler |
| 1970-1981 | Pontiac Firebird |
| Attributes | |
| ASIN | B004TB3NPK |
| Application | GM LS Engines, GM LS Engines |
| Baffled | No |
| Brand | Holley, Holley |
| California Proposition 65 | No |
| Capacity | 5.5 qt., 5.5 |
| Category | Intake Manifolds, Engine |
| Category Filter | Intake Manifolds |
| Choose Your Part | Oil Pan Kit, Oil Pan Kit |
| Clearance Category | Intake Manifolds |
| Color | Silver |
| Country of Origin (Primary) | US |
| Crank Shaft Wiper Included | No |
| Dipstick Port | No |
| Drain Plug Included | Yes |
| Emission Code | 5, 5 |
| Engine | GM Gen III/IV (LS), GM Gen III/IV (LS) |
| Engine Make/Size | Chevy Small Block LS Series |
| Finish | Cast, Natural Cast |
| GTIN | 00090127669648 |
| Grade Type | Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Material | Aluminum |
| Maximum Stroke | 4.25", 4.25" |
| NAFTA Preference Criterion Code | B |
| Oil Pan Capacity | 5.5 Quarts, 5.5 Quarts |
| Oil Pan Type | Cast, Cast |
| Pickup Included | Yes |
| Product Type | Oil Pans, Oil Pan Kit |
| SDR Required Flag | N |
| Sale Category | Engine |
| Sub Category | Cylinder Block Components |
| Sump Location | Rear |
| Sump Type | Wet |
| Turbo Oil Drainback | No, No |
| Usage | OEM |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Limited 90 Day, Manufacturer's Limited 90 Day Warranty |
| Windage Tray Included | No |
| part type | Engine Oil Pan |
Holley 302-1 Holley GM LS Swap Oil Pan
Product Information
- Brand: Holley
- Product Number: 302-1
