Fits most GM Gen V LT Engines with OE-type LT Cylinder Heads
Holley's new single-plane Gen V LT intake manifold was designed with an optimized runner layout and constant cross-sectional area, resulting in a broad torque curve with the best vehicle performance from 2500-7000 RPM.
Holley's new single-plane Gen V LT intake manifold was designed with an optimized runner layout and constant cross-sectional area, resulting in a broad torque curve with the best vehicle performance from 2500-7000 RPM.
- Cast aluminum construction - great manifold for centrifugal blower, turbocharged or NOS mild power adder applications
- 4150 Square bore flange
- 2500-7000 RPM power band
- Provides classic engine bay look of carb style intake
- Height (front) - 5.417" to the lifter valley cover flange at the engine block front flange and bellhousing flange
- Weight - 11.5 lbs.
- Optimized runner layout and constant cross sectional area - broad torque curve, best vehicle performance from 2500-7000 RPM
- Efficient casting design - lightweight, consistent wall thicknesses, improved casting quality
- Minimum carb flange height - fit in vehicles with minimum hood modifications
- Port size - 2.33" height x 1.27" wide
- Includes FKM o-ring intake to cylinder head gaskets
Information:
Includes mounting hardware, O-ring cylinder head mounting flange gaskets, MAP Sensor port cover, and vacuum port plugs.| Attributes | |
| Basic Operating RPM Range | 2500-7000 |
| Brand | Holley |
| Category | Air and Fuel Delivery, Air and Fuel Delivery |
| CNC Ported | No |
| Color | Black, Black |
| Construction | Cast, Cast |
| Country of Origin (Primary) | CN |
| Cylinder Head Port Shape | Rectangle |
| Deck Height | 9.24 |
| EGR Port | No, No |
| Emission Code | 3, 3, Off Road |
| Engine | GM Gen V LT1, GM Gen V LT1 |
| Finish | Satin |
| Flange Style | 4150, 4150 |
| Front Height | 5.417 inch |
| Front Maximum Height | 5.417, 5.417 |
| Fuel Injectors Included | No, No |
| Fuel System Type | EFI, EFI |
| Gasket Or Seal Included | No, No |
| Grade Type | Performance, Performance |
| Harmonized Tariff Code (Schedule B) | 8409915085 |
| Hazardous Material Code | N |
| Life Cycle Status Code | Available to Order |
| Manifold Type | Single Plane, Single Plane |
| Material | Aluminum, Aluminum |
| part type | Engine Intake Manifold |
| Plenum Finish | Black, Black |
| Product Type | Intake Manifold, Intake Manifold |
| Rear Height | 5.417 inch |
| Rear Maximum Height | 5.417, 5.417 |
| Recommended Use | Forced Induction, Forced Induction |
| RPM Power Band | 2500-7000 RPM |
| SDR Required Flag | N |
| Single Or Dual Plane Type | Single Plane, Single Plane |
| Throttle Body Bore Diameter | 3.6, 3.6 |
| Throttle Body Gasket Included | No, No |
| Vacuum Ports | Yes, Yes |
| Warning | California Proposition 65, California Proposition 65 |
| Warranty | Manufacturer's Limited 90 Day Warranty, Manufacturer's Limited 90 Day Warranty |
| GTIN | 00090127617755 |
