Cat-Back Dual Extreme Exhaust System; Aluminized
For the extremist who wants to take their truck to the next level, this dual bolt-on Cat back system is for you. This system exists behind the rear tires at an aggressive angle with a powerful exhaust tone. You will gain bold street looks with powerful dyno tuned and tested street performance gains. You can expect to experience gains on average of 15-20 horsepower. Gibson muffler provides a mean performance sound and complemented with polished Stainless Tip. Easy bolt-on installation. No welding required. Backed by a Lifetime Limited Warranty. If you want Extreme, this system is it.
- Aluminized Mandrel Bent Tubing
- Superflow™ CFT Muffler
- Baffled/Chambered Muffler; No Internal Packing
- Minimal Interior Drone - Aggressive Sound
- Polished Stainless Slash-Cut Clamp On Tips
- Incl. All Hardware/Factory Style Hangers
- Hassle Free Bolt-On Installation
- Lifetime Limited Warranty
Application Summary:
| Year |
Make/Model |
| 2017-2018 |
Ford F-250 Super Duty |
| 2017-2018 |
Ford F-350 Super Duty |
| Attributes |
| Additional Description |
Includes all hardware and factory style hangers for easy bolt on installation. |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Clamps Included |
Yes |
| Country of Origin (Primary) |
US |
| EMISSION CARB # |
50 State Legal California Emissions Compliant |
| Emission Code |
Legal US |
| Exhaust Type |
Dual |
| Exit Position |
Dual Split Rear Behind Rear Tires |
| Exit Style |
Straight |
| GTIN |
00677418029994 |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Inside Diameter |
2.500 in. |
| Inlet Inside Diameter (in.) |
2.5 |
| Inlet Size (in.) |
2.5 |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2.500 in. |
| Main Piping Diameter (in.) |
2.5 |
| Material |
Aluminized |
| Mounting Bracket Included |
Yes |
| Muffler Body Diameter |
7.000 in. x 7.000 in. |
| Muffler Body Diameter (in.) |
7 x 7 |
| Muffler Body Finish |
Aluminized |
| Muffler Body Length |
24.000 in. |
| Muffler Body Length (in.) |
24.000 |
| Muffler Configuration |
Center/Dual |
| Muffler Count |
1 |
| Muffler Dimension |
7 in. Round , 3 in. Center Inlet , 2.50in. Dual Outlet , L 24 in. |
| Muffler Type |
Chambered |
| NAFTA Preference Criterion Code |
B |
| Outlet |
Dual |
| Outlet Outside Diameter |
2.500 in. |
| Outlet Outside Diameter (in.) |
2.5 |
| Outlet Size (in.) |
2.5 |
| Product Warranty |
Lifetime Limited Warranty |
| SDR Required Flag |
N |
| Sound Level |
Aggressive |
| System Type |
Cat Back |
| Tail Pipe Diameter |
2.500 in. |
| Tail Pipe Quantity |
2 |
| Tip Description |
4in. Polished T304 Stainless Rolled Slash Cut Tip. |
| Tip Diameter |
4.000 in. |
| Tip Finish |
Polished |
| Tip Logo |
None |
| Tip Quantity |
2 |
| Tip Size |
4.0 in. |
| Tip Specification |
Inlet 2.50 in. , Outlet 4.0 in. , L 12 in. |
| Tubing Diameter |
2.500 in., 2.500 in. |
| Vehicle Category |
Truck and Suv |
