Cat-Back Dual Split Exhaust System; Stainless
Gibson Single Side Exhaust is perfect for improved acceleration, maximum hill climbing, towing and passing power. This is our best performing Exhaust System. Exits behind the rear tire. Quieter in the cab than any other Performance Exhaust. Dyno test results show it makes maximum torque and horsepower at low-end (1800 to 3000 RPM). Horsepower gains average 10-15 and 15-20lb-ft of increase torque. Hassle free, bolt-on installation with professional looking results. No welding required. Backed by a Lifetime Limited Warranty.
- Stainless Mandrel Bent Tubing
- Superflow™ Muffler
- Baffled/Chambered Muffler; No Internal Packing
- Minimum Interior Drone; Aggressive Sound
- Polished Stainless Slash-Cut Tip[s]
- Hassle Free Easy Bolt On Installation
- No Welding Or Cutting Required
- Lifetime Limited Warranty
Information:
409L Stainless Steel Heavy Duty Tubing; Mandrel Bent Tubing; Aluminized Superflow™ Muffler; Stainless Steel Clampless Slash Tips; Zinc Plated 3/8 in. to 1/2 in. Hangers/Clamps; Lifetime Limited Warranty
Application Summary:
| Year |
Make/Model |
| 2011-2014 |
Ford F-150 |
| Attributes |
| Additional Description |
Includes all hardware and factory style hangers for easy bolt on installation. |
| California Proposition 65 |
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
| Country of Origin (Primary) |
US |
| Description |
Includes all hardware and factory style hangers for easy bolt on installation. |
| EMISSION CARB # |
50 State Legal California Emissions Compliant |
| Emission Code |
Legal US |
| Exhaust Type |
Cat-Back |
| Exit Position |
Behind Rear Tire |
| Exit Position (F05) |
Exits Behind Rear Tire. |
| Exit Style |
Straight |
| Footnote |
Will not Fit SVT Raptor or Harley Davidson Edition |
| GTIN |
00677418024197 |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Inlet Inside Diameter |
3.000 in. |
| Inlet Inside Diameter (in.) |
3 |
| Inlet Size (in.) |
3 |
| Life Cycle Status Code |
Available to Order |
| Material |
Stainless Steel |
| Muffler Body Length |
19.000 in. |
| Muffler Body Length (in.) |
19.000 |
| Muffler Dimension |
7 in. Round Body; 3.00 in. Center Inlet; 2.50 in. Dual Outlet; L-19 in. |
| Muffler Type |
Chambered |
| NAFTA Preference Criterion Code |
B |
| Outlet |
Dual |
| Outlet Outside Diameter |
2.5 |
| Outlet Outside Diameter (in.) |
2.5 |
| Outlet Size (in.) |
2.5 |
| Product Warranty |
Lifetime Limited Warranty |
| SDR Required Flag |
N |
| System Type |
Cat Back |
| Tail Pipe Diameter |
2.500 in. |
| Tip Description |
3.50in. Polished T304 Stainless , Round Slash Cut Tip , Clamp on. |
| Tip Description _3_ 80_c _short description_ (F05) |
3.50in. Polished T304 Stainless; Round Slash- Cut Tip; Clamp on. |
| Tip Diameter |
3.500 in. |
| Tip Logo |
None |
| Tip Size |
3.5 in. |
| Tip Specification |
Inlet 2.50in. , Outlet 3.50in. , L 12in. |
| Tip Specifications (F05) |
Inlet 2.50in.; Outlet 3.50in.; L-12in. |
| Tubing Diameter |
3.00 in. / 2.50 in. |
| Vehicle Category |
Truck & Suv |
