Fits 2023-2025 GM Colorado / Canyon 2.7-Liter, Cat-Back, Dual Out Same Side Exit, Stainless Steel Exhaust System
This Flowmaster® FlowFX® cat-back exhaust system is for the 2023-2025 GM Colorado/Canyon with the 2.7-liter turbo engine. This system is manufactured using durable 409 stainless steel tubing and features 3.00-inch to dual 2.5-inch mandrel bent pipes for better exhaust gas flow. A FlowFX "straight-through" muffler is used for an aggressive to moderate sound level and maximum performance. Maximum increases on the dyno revealed 14 hp and 15 lb-ft at the rear wheels. This system exits out the side of the truck in front of the rear tire with dual 4.00-inch black ceramic coated tips for added style. The system uses all the existing factory hanger locations and includes installation instructions and all necessary hardware for an easy installation that you can do at home. Backed by Flowmaster's Lifetime Limited Warranty.
- 3.00-inch mandrel bent 16-gauge 409 stainless steel tubing maximizes exhaust flow and improves durability
- High clearance muffler and tailpipe designed for improved departure angles with the roughest terrain
- Includes complete hardware and factory styled hangers in the stock locations for an easy installation
- FlowFX “straight through” performance muffler delivers a deep, moderate to mild performance tone and improves exhaust flow
- Max increases of up to 14 hp and 15 lb-ft over the stock exhaust at the wheels
- Lifetime Limited Warranty
Information:
Will not fit with running boards or rock sliders
Application Summary:
| Year |
Make/Model |
| 2023-2024 |
Chevrolet Colorado |
| 2023-2024 |
GMC Canyon |
| Attributes |
| Brand |
Flowmaster |
| California Proposition 65 |
Yes |
| Catalytic Converter Quantity |
Not Included |
| Category |
Exhaust |
| Country of Origin (Primary) |
US |
| Emission Code |
5 |
| Exhaust Series |
FlowFX |
| Exhaust System Kit Type |
Cat-Back |
| Exhaust Tip Diameter |
4.00 |
| Exhaust Tip Length |
5.25 |
| Exit Position |
DOSS |
| GTIN |
00090127852330 |
| Harmonized Tariff Code (Schedule B) |
8708925000 |
| Hazardous Material Code |
N |
| Life Cycle Status Code |
Available to Order |
| Main Piping Diameter |
2-1/2 |
| Material |
409 Stainless Steel |
| Mount Type |
Uses Factory Hangers |
| Muffler Body Height |
4.00 |
| Muffler Body Length (in) |
14 |
| Muffler Body Width |
9.00 |
| Muffler Color |
Natural, Silver |
| Muffler Inlet Diameter |
3.00 |
| Muffler Inlet Inside Diameter |
3.00 |
| Muffler Inlet Location |
Centered, Center |
| Muffler Inlet Outside Diameter |
3.13 |
| Muffler Material |
409S Stainless Steel, 409 Stainless Steel |
| Muffler Outlet Diameter |
2.50 |
| Muffler Outlet Location |
dual outlet - offset (opposite sides), Dual |
| Muffler Overall Length |
20.00 |
| Muffler Overall Length (in) |
20 |
| Muffler Part Number |
Kit Only |
| Muffler Series |
FlowFX |
| Muffler Shape |
Oval |
| Product Type |
Exhaust System |
| SDR Required Flag |
N |
| Single Dual |
Dual |
| Sound Level |
Aggressive / Moderate |
| Sub Category |
Exhaust and Tail Pipes |
| System Type |
Cat-back |
| Tail Pipe Outlet Outside Diameter |
2.50 |
| Tip Cut |
Angle |
| Tip Diameter |
4.00 |
| Tip Edge Style |
Machined |
| Tip Finish |
Black Ceramic, Black Ceramic Coating |
| Tip Length |
5.25 |
| Tip Logo |
Laser |
| Tip Material |
304 Stainless, 304 Stainless Steel |
| Tip Quantity |
2.00 |
| Tip Style |
Double Wall |
| Tubing Diameter |
2.50 |
| Tubing Diameter (in) |
2.50 |
| Tubing Material |
409S Stainless Steel, 409 Stainless Steel |
| Warning |
California Proposition 65 |
| part type |
Exhaust System Kit |
